Helon HLBY02 Tube Light/Fluorescent Explosion Proof

Description

Helon HLBY02 adalah salah satu dari seri lampu tube light / lampu tabung LED / T8 berstandar anti ledakan (explosion proof) yang didesain lebih minimalis, cocok untuk penggunaan indoor dalam area industri rawan ledakan.

Produk dari Helon Explosion Proof telah terpasang dengan sangat baik di berbagai industri klasifikasi hazardous area seperti industri minyak dan gas (oil and gas), petrokimia, oleokimia, yang telah mengantongi berbagai sertifikasi explosion proof seperti IECEx (IEC), ATEX (Cenelec dan EN), dan China Ex yang telah diakui dimata internasional di lebih dari 50 negara seperti Timur Tengah, Asia Tenggara, Rusia, Kazakshtan dan Afrika.

Kami menyediakan lampu highbay dan lowbay explosion proof (biasa dikenal sebagai lampu gantung / pendant light explosion proof), floodlight explosion proof (lampu sorot), lampu tube light (TL) explosion proof, warning light / caution light explosion proof, inspection light explosion proof, hingga emergency light/lampu darurat explosion proof.

PT Helon Internusa Flamindo umumnya memberikan layanan gratis jasa pengiriman ke seluruh Indonesia, namun secara diprioritaskan pengiriman ke wilayah Jabodetabek (Jakarta, Bogor, Tangerang, Depok, Bekasi) dan sekitarnya seperti Karawang, Cilegon, Serang, Rangkasbitung, Indramayu, Cilacap, Tuban, dan sekitarnya.

Helon HLBY02 Tube Light/Fluorescent Explosion Proof

827.6 KB

Helon HLBY02 Tube Light Fluorescent Explosion Proof

Ex marking	Gas	Fluorescent tube		Ex eb mb IICT4 Gb
		LED Module		Ex db e IC T6 Gb
		LED Module with emergency		Ex db eb mb IIC T6 Gb
	Dust			Ex tb IIIC T80℃ Db
Conformity to standards		GB3836.1,GB3836.2,GB3836.3,GB3836.9,GB12476.1,GB12476.5
Structure Material	Enclosure	Bending steel plate,powder coated,white color,or bending stainless steel plate
	Transparent cover	Tempered glass,resistant to 4J impact
	Tube Replacing	The special hinge and quick opening structure,easy to maintenance
	Ballast	Explosion-proof electronic ballast,wide voltage output(150~250VAC),power factor ≥0.95,with protection function of short circuit,overload,lamp aging,lamp damage,and power asymmetric of the lamp tube
	Explosion proof LED Module	Wide voltage input(180~265VAC)constant power output,power factor ≥0.95,with protection function of shunt,open circuits,hort circuit,etc.
	Emergency unit	Ex emergency unit,when the power supply is off,the lamp will automatically switch to the emergency lighting state
	Exposed fastener	Stainless steel
Light source	Specification	T8 fluorescent tube		T5 fluorescent tube		T8 Ex LED Module
	Power (W)	18WX1	18WX2			9WX1	9WX2
		36WX1	36WX2	28WX1	28WX2	18WX1	18WX2
Rated voltage		T8/T5 fluorescent tube:150～250VAC,50/60Hz
		LED Module:180～265VAC,50/60Hz
Degree of protection		IP65
Ambient temperature		-20℃~+40℃
Terminal block		3×1.5～4mm²(L+N+PE)
Cable entries		1×φ25:1-M25×1.5
Available cable outer diameter (mm)		o10~φ14(mm)
Emergency unit technical parameters	Emergency unit	Dedicated emergency controller and battery pack,with overcharge and over discharge protection functions
	Emergency power(W)	T8 fluorescent tube:1X18W,1X36W T5 fluorescent tube:1X28W T8 LED Module:1X9W,1X18W
	Emergency starting time	0.3s
	Charging time	24h
	Emergency lighting time	90min
