Helon HLBD05 LED Highbay Explosion Proof

Description

Helon HLBD05 adalah lampu sorot/high bay berstandar explosion proof yang tersertifikasi IECEx, ATEX dan China Ex (Gb) dan IP66 untuk penerangan area industri luas dan ketingggian dengan efisiensi energi tinggi. Produk ini telah tersertifikasi ATEX, IECEx, dan IP66 sehingga tahan terhadap debu dan percikan air untuk kebutuhan area hazardous.

Produk Helon Explosion Proof telah digunakan di berbagai industri minyak dan gas (oil & gas), petrokimia (petrochemical), dan oleokimia (oleochemical) dengan dukungan sertifikasi internasional seperti IECEx, ATEX, dan China Ex yang digunakan di lebih dari 50 negara di kawasan Timur Tengah, Asia Tenggara, Rusia, Kazakhstan, dan Afrika.

PT Helon Internusa Flamindo menyediakan berbagai lampu explosion proof untuk area hazardous seperti highbay dan lowbay pendant light, floodlight/lampu sorot, tube light (TL), warning light, inspection light, hingga emergency light explosion proof untuk kebutuhan industri oil & gas, petrokimia, manufaktur, dan fasilitas rawan ledakan lainnya.

Layanan pengiriman tersedia ke seluruh Indonesia dengan prioritas area Jabodetabek dan kawasan industri seperti Karawang, Cilegon, Serang, Indramayu, Cilacap, Tuban, dan sekitarnya.

Helon HLBD05 LED Highbay Explosion Proof

1.5 MB

Download Helon HLBD05 LED Highbay Explosion Proof

Ex marking	Gas	Ex II 2 G Ex db op is IIC T6/T5 Gb		Ex db op is IIC T6/T5 Gb		Ex d IIC T6/T5 Gb
	Dust	Ex II 2 D Ex tb op is IIIC T80/T95℃ Db		Ex tb op is IIIC T80/T95℃ Db		Ex tD A21 IP66 T80/T95℃
Conformity to standards		IEC60079-0,IEC60079-1,IEC60079-28,IEC60079-31 EN60079-0,EN60079-1,EN60079-28,EN60079-31 GB3836.1,GB3836.2,GB12476.1,GB12476.5
Structure, Material	Enclosure	Aluminum alloy enclosure,powder coated,industrial grey with dark lines texture (RAL7035)
	Transparent cover	Tempered glass,resistant to 4J impact,type ll has a larger irradiation angle
	Protective grid	Steel wire powder coating (white)or stainless steel,please note when needed
	LED power	Wide voltage input (90~305VAC),constant power output,power factor ≥0.95.With protection functions of constant current,over current,open circuit,short circuit,surge prevention,etc.
	Emergency unit	Explosion-proof emergency unit,when the power supply is off,the lamp will automatically switch to the emergency lighting state
	Irradiation angle	30°,45°,60°,adjustable angle of the mounting bracket
	Exposed fastener	Stainless steel
Light source	Specification	LED (Cree),multiple arrangement,luminous efficiency >140 Im/W,color rendering >70
	Power(W)	LED:20W,25W,30W,45W,50W,60W,70W,85W,100W,120W
	LED (CCT) color temperature	Cool white:5700K (default) Note:Warm white (3000K)and natural white (4000K)can be customized,please note it when ordering.
Rated voltage		Mingwei:90-264V AC,Inventronics:90-305VAC
Frequency		50/60Hz
Degree of protecton		IP66
Ambient temperature	Mingwei power supply	HLBD05-Ⅰ			HLBD05-Ⅱ
		20W-60W	70W-120W		20W-70w		85W-120W
		-40℃-+55℃:T6	-40℃~+40℃:T6 -40℃-+55℃:T5		-40℃~+55℃:T6		-40℃~+40℃:T6 -40℃~+55℃:T5
	Inventronics power supply	HLBD05-I(Ⅱ)
		20W～60W	70W-120W
		-40℃-+55℃:T6	-40℃~+40℃:T6 -40℃~+55℃:T5
Terminal block		3X1.5～4mm²(L+N+PE)
Cable entries		1-G3/4 or M25X1.5 or NPT3/4(Pendant type,Spotlight type) 2-G3/4 orM25X1.5 orNPT3/4 (Wall type,pendant type with junction box,hanging chain type,ceiling type) 4-G3/4 or M25X1.5 or NPT3/4(Ceiling type) Note:The thread hole with stop plug is M25X1.5or NPT3/4,and the thread hole with cable gland is M25X1.5,NPT 3/4,or G3/4(with rubber sealing ring)
Available cable outer diameter(mm)		φ9-φ14(mm)

Size(mm) Power(W)	A	B	φC	D	E	F	G	H	I
20,25,30	250	235	238	291	275	283	298	383	323
45,50,60	260	245	248	345	285	293	308	393	333
70	282	264	248	367	304	312	330	415	352
85,100,120	288	270	300	373	310	318	336	421	358
